- 8 × Gigabit PoE ports, 1 × Gigabit RJ45 port, 1 × Gigabit SFP fiber optical port
- IEEE 802.3at/af standard
- IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z standard
- 6 KV surge protection for PoE ports
- PoE power management
- Gigabit network access
- Wire-speed forwarding and non-blocking design
- Store-and-forward switching
- Solid high-strength metal shell
- Reliable fan-free design

Hikvision DS-3E0510P-E/M 8 Port Gigabit Unmanaged POE Switch
₹4,144.00
Check if the product is available for delivery to your location
Hikvision 8 Port Gigabit Unmanaged POE Switch.
Technical Specifications
Brand | Hikvision |
Model No | DS-3E0510P-E/M |
Model Name | Unmanaged POE Switch |
Port Number | 8 × Gigabit PoE ports, 1 × Gigabit RJ45 port, 1 × Gigabit SFP fiber optical port |
Port Type | RJ45 port, full duplex, MDI/MDI-X adaptive |
Switching Capacity | 20 Gbps |
PoE Standard | IEEE 802.3af, IEEE 802.3at |
PoE Power Pin | Ethernet cable 1/2/3/6 provide power supply |
Max. Port Power | 30 W |
PoE Power Pudget | 58 W |
Max. Power Consumption | 65 W |
Shell | Metal material, no fan equipped |
Power Supply | 48 VDC, 1.35 A |
Power Consumption In Idle | 7 W |
Dimension | 217.6 mm × 27.8 mm × 108.55 mm |
Weight | 1.366 kg |
