Dlink DPS-F1B08 8 CH CCTV Power Supply

Availablity: In stock


Check if the product is available for delivery to your location


Dlink DPS-F1B08 8 CH CCTV Power Supply.

  • Highly Efficient & Consumes Low Power
  • Stabilized Output, Low Interference, Surge Protected
  • Over Heat & Voltage Protection
  • Highly Integrated SMPS Switcher I.C Design
  • Over Load Protection
  • Short Circuit Auto Restart
  • Input Voltage-110VAC-300VAC 47/53Hz
  • Output Voltage - 12V- 1 AMP max per channel.

Technical Specifications

Brand D-Link
Model No DPS-F1B08
Model Name 8 CH CCTV Power Supply
Input Voltage Range 110VAC~300VAC
Frequency 47Hz - 53Hz
Output Voltage 12.0 VDC
Line Regulation 11.40-12.60VDC
Setup Rise time < 10 mSec. at 230VAC input.
Hold up time > 10 mSec. at 110VAC Input
Inrush current < 50A Peak @ 230VAC Cold start at 25 Deg.
Leakage Current <0.25mA / 265VAC
Auto Reset During over load and short circuit
Input Overvoltage Protection The power supply is withstand upto 330VAC, without Interrupting
Over Load Protection Auto restart
Ripple <240mV
Surge protection 4 KV
Efficiency > 75% at all load conditions with complete AC input Operating Voltage (110VAC - 300VAC).
Housing Metallic cabinet Powder coating mat finish
Store Temperature -15° to +70° C ambient
Working Humidity 10 ~ 90% RH Non-Condensing
Working Temperature 0ºC to +50ºC with 3.5A, +30ºC Deg with 4.0A
Warranty 2 Years
